Description
Technical Specifications:
- Operating Frequency: 13.56 MHz
- Chip Type: NXP MIFARE Classic 1K
- User Memory: 1024 Bytes (16 sectors of 4 blocks)
- UID size: 4 Bytes
- Range: Up to 10 cm (depending on antenna geometry)
- Data Transfer Rate: up to 106 kbps
- Communication Protocol: ISO/IEC 14443-A
- Dimensions: 40 x 32 mm
- Material: ABS
- Factory default A/B key: FF FF FF FF FF FF
Features:
- Durable and waterproof ABS material
- Small and portable design, easy to carry.
- Compatible with various NFC-enabled devices including ACR122U reader.
- Uses CRYPTO1 encryption to protect data transmission and access control.
Applications:
MIFARE Classic 1K RFID Key Fobs are commonly used for electronic access control, such as in residential and commercial buildings, parking facilities, and public transportation systems. They can also be used for payment and loyalty programs, event ticketing, and identification purposes. The MIFARE Classic 1K technology allows for read and write capabilities, making it ideal for applications requiring data storage and frequent updates.
Specifications
| Weight | 0.005 kg |
|---|---|
| Color | Blue, Yellow, Red, Green, Black |
| Application | Access Control System |
| Chip | |
| Communication Interface | HF RFID |
| Frequency | |
| Material | ABS |
| Protocol | |
| Size | 41x33MM |
| Package | 1 Piece, 10 Pieces, 100 Pieces, 500 Pieces, 1,000 Pieces |
